Coordinate measuring machines are reliable in their measuring accuracy – however they need to be routinely qualified and checked. CMM checks are used for standard-compliant accuracy checks, and reference bodies (spheres and other gauges) are used to qualify sensors and styli in everyday life.
7.536,00 DKKexcl. VAT
 Shipment within 2 Working days
3.600,00 DKKexcl. VAT
 Shipment within 2 Working days
9.808,00 DKKexcl. VAT
 Shipment within 2 Working days
7.096,00 DKKexcl. VAT
 Shipment within 2 Working days
Reference Sphere DK 25, DG 18, M6
600332-8445-000
Ø Sphere (DK)
25,0 mm
Length (L)
82,5 mm
Styl. Tip Mat.
Ceramic
3.304,00 DKKexcl. VAT
 Shipment within > 30 Working days
Reference Sphere DK 25, DG 18, M6 (µ50 porosity)
600332-8455-000
Ø Sphere (DK)
25,0 mm
Length (L)
82,6 mm
Styl. Tip Mat.
Ceramic
3.000,00 DKKexcl. VAT
 Shipment within 2 Working days
110.800,00 DKKexcl. VAT
 Shipment within 2 Working days
Rotary table set
626106-9370-000
27.600,00 DKKexcl. VAT
 Shipment within 2 Working days
Complete reference sphere kit, DK 25, 105 mm, M6 base
600332-9486-000
Ø Sphere (DK)
25,0 mm
Length (L)
105,0 mm
Styl. Tip Mat.
Ceramic
6.181,00 DKKexcl. VAT
 Shipment within 2 Working days
Reference Sphere DK 45, DG 18, M6
600332-8447-000
Ø Sphere (DK)
45,0 mm
Length (L)
92,5 mm
Styl. Tip Mat.
Ceramic
7.736,00 DKKexcl. VAT
 Shipment within 2 Working days
Reference Sphere DK 15, DG 18, M6
600332-8444-000
Ø Sphere (DK)
15,0 mm
Length (L)
77,5 mm
Styl. Tip Mat.
Ceramic
3.216,00 DKKexcl. VAT
 Shipment within 2 Working days
6.640,00 DKKexcl. VAT
 Shipment within 2 Working days
3.448,00 DKKexcl. VAT
 Shipment within 2 Working days
Complete reference sphere kit, DK 30, 214 mm, M10 base
600332-9268-000
Ø Sphere (DK)
30,0 mm
Length (L)
214,0 mm
Styl. Tip Mat.
Ceramic
10.472,00 DKKexcl. VAT
 Shipment within 2 Working days
Complete reference sphere kit, DK 30, 187 mm, (Matt finish) Magnetic base
600332-9269-000
Ø Sphere (DK)
30,0 mm
Length (L)
187,0 mm
Styl. Tip Mat.
Tung. Carb.
11.352,00 DKKexcl. VAT
 Shipment within 2 Working days
CT Check Nano
626106-9340-030
152.000,00 DKKexcl. VAT
 Shipment within 2 Working days
8.416,00 DKKexcl. VAT
 Shipment within 2 Working days
Complete reference sphere kit, DK 25, 214 mm, M10 base
600332-9258-000
Ø Sphere (DK)
25,0 mm
Length (L)
214,0 mm
Styl. Tip Mat.
Ceramic
10.472,00 DKKexcl. VAT
 Shipment within 2 Working days
Reference Sphere DK 25, DG 24, M8
626106-0041-000
Ø Sphere (DK)
25,0 mm
Length (L)
140,0 mm
Styl. Tip Mat.
Ceramic
2.568,00 DKKexcl. VAT
 Shipment within 2 Working days
Reference Sphere DK 30, DG 18, M6 ( Matt finish) (Higher accuracy sphere)
600332-8476-000
Ø Sphere (DK)
30,0 mm
Length (L)
85,0 mm
Styl. Tip Mat.
Ceramic
12.232,00 DKKexcl. VAT
 Shipment within 2 Working days
15.216,00 DKKexcl. VAT
 Shipment within 2 Working days
14.304,00 DKKexcl. VAT
 Shipment within 2 Working days
13.800,00 DKKexcl. VAT
 Shipment within 2 Working days
11.256,00 DKKexcl. VAT
 Shipment within 2 Working days
Reference bodies and holders

Reference bodies and holders

Reference spheres and bodies ensure the measuring accuracy in everyday life, and with reference to each new styli or sensor qualification. They can be optical gauges, reference spheres, ring gauges or triplets, all of which have a zero point in their center to guide the coordinate measuring machine. Depending on the measuring environment, thermally stable or standard holders are available for positioning the reference body. All products and certifications related to the coordinate measuring machine are available from ZEISS from a single source.
ZEISS CMM Checks  - conforming to standards

ZEISS CMM Checks - conforming to standards

Coordinate measuring machines shall be inspected regularly according to ISO quality standards 9000-9004. The procedure for acceptance and confirmation testing is described in detail in ISO 10360. CMM Checks are test specimens with a high-precision calibrated values, corresponding to the standard-compliant procedures for coordinate measuring machines according to VDI/VDE 2617 Sheet 5 and DIN EN ISO 10360. VDA 5 and VDI/VDE 2617 Sheet 8 are decisive for determining the suitability of the test process. The test specimens are also suitable for testing contour measuring machines according to VDI/VDE Guideline 2629. The measurement uncertainty can be determined according to ISO 15530 for certain geometrical elements.
